Product Highlights
- ClearCut fabricated cutting deck: The new fabricated design features welded 10 gauge steel construction with additional welded reinforcement strips for maximum durability
- Kawasaki engine: Kawasaki engines offer smooth, quiet, reliable power. Heavy-duty components offer long life and electric start is standard.
- Maintenance-Free Transmission: Worry free performance with maintenance free, integrated zero-turn transmissions.
- Rugged frame and casters: The robust frame and casters ensure durability and reduced chassis flex.
Specifications
| Z248FSKU: 970 45 89‑01 | |
| Homeowner Warranty | 3 Years |
| Commercial Warranty | No Warranty |
| Capacity | |
| Productivity | 2.5 acres/hr |
| Speed forward max | 6.5 mph |
| Speed forward min | 0 mph |
| Cutting deck | |
| Cutting width | 48in |
| Cutting deck type | ClearCut – Fabricated |
| Cutting methods | Collect/Mulch/Side discharge |
| Cutting deck material | Steel |
| Deck thickness | 10 gauge |
| Cutting height steps | 6 |
| Blade engagement | Electric clutch |
| Clutch rating | 87 ft.lb |
| Blades | 3 pcs |
| Blade-tip speed | 18,500 fpm |
| Anti-scalp wheels | 3 |
| Nose roller | Yes |
| Deck lifting system | Manual, hand operated |
| Powder-coated cutting deck | Yes |
| Spindle/mandrel type | Cast iron |
| Greasable mandrels | Yes |
| Deck Wash Port | Yes |
| Cutting height, min-max | 1.5-4 in |
| Dimensions | |
| Base machine, length | 75 in |
| Base machine, height | 40 in |
| Base machine, width (chute down) | 60 in |
| Base machine, width (chute up) | 50 in |
| Weight | 595 lbs |
| Tire size, front Width | 6 in |
| Tire size, front Diameter | 11 in |
| Tire size, front Diameter wheel | 5 in |
| Drive System | |
| Transmission type | Hydrostatic |
| Transmission manufacturer | Hydro-Gear |
| Transmission manufacturer | Hydro-Gear |
| Pump displacement | 10 cm³ |
| Fan-cooled pumps | Yes |
| Engine | |
| Motor/engine manufacturer | Kawasaki |
| Engine name | FR Series |
| Power output | 23 hp |
| Cylinder displacement | 726 cm³ |
| Cylinders | 2 |
| Engine cooling | Air |
| Air filter type | Auto-type Paper |
| Power/fuel type | Gasoline |
| Engine lubrication type | Full pressure with oil filter |
| Oil filter | Yes |
| Fuel tank volume (with reserve) | 3.5 gal (US) |
| Fuel tank location | Side (Single) |
| Equipment | |
| Seat material | Vinyl |
| Seat spring | Yes |
| Seat back height | High |
| Hour meter type | Digital with pre-programmed service intervals |
| Cup holder | Yes |
| Hinged armrests | Standard |
| Seat type | Comfort high back |
