Product Highlights
- Automatic park brake system
- ClearCut fabricated cutting deck
- Kawasaki engine: Kawasaki engines offer smooth, reliable power
- Maintenance-Free Transmission: Maintenance-free hydraulic transmission
- Rugged frame and casters: Rugged frame and casters ensure durability
- Convenient deck lift
- Ergonomic control panel
- Comfortable Seat: Deluxe Comfort Seat
- Removable foot plate
- Anti-slip foot area
- Bumper
- Refinement
- Rear engine guard
Specifications
| Warranty | Z242F SKU: 967 95 38‑01 | Z242F SKU: 967 95 38‑03 |
| Homeowner Warranty | 3 Years | 3 Years |
|---|---|---|
| Commercial Warranty | No Warranty | No Warranty |
| Capacity | ||
| Productivity | 2.2 acres/hr | 2.2 acres/hr |
| Speed forward max | 6.5 mph | 6.5 mph |
| Speed forward min | 0 mph | 0 mph |
| Cutting deck | ||
| Cutting width | 42in | 42in |
| Cutting deck type | ClearCut – Fabricated | ClearCut – Fabricated |
| Cutting methods | Collect/Mulch/Side discharge | Collect/Mulch/Side discharge |
| Cutting deck material | Steel | Steel |
| Deck thickness | 10 gauge | 10 gauge |
| Cutting height steps | 6 | 6 |
| Blade engagement | Electric clutch | Electric clutch |
| Clutch rating | 87 ft.lb | 87 ft.lb |
| Blades | 2 pcs | 2 pcs |
| Blade-tip speed | 18,500 fpm | 18,500 fpm |
| Anti-scalp wheels | 1 | 1 |
| Nose roller | Yes | Yes |
| Deck lifting system | Manual, hand operated | Manual, hand operated |
| Powder-coated cutting deck | Yes | Yes |
| Spindle/mandrel type | Cast iron | Cast iron |
| Greasable mandrels | Yes | Yes |
| Deck Wash Port | Yes | Yes |
| Cutting height, min-max | 1.5-4 in | 1.5-4 in |
| Dimensions | ||
| Base machine, length | 75 in | 75 in |
| Base machine, height | 40 in | 40 in |
| Base machine, width (chute down) | 51 in | 51 in |
| Base machine, width (chute up) | 43.5 in | 43.5 in |
| Weight | 551 lbs | 551 lbs |
| Drive System | ||
| Transmission type | Hydrostatic | Hydrostatic |
| Transmission manufacturer | Hydro-Gear | Hydro-Gear |
| Transmission manufacturer | Hydro-Gear | Hydro-Gear |
| Engine | ||
| Motor/engine manufacturer | Kawasaki | Kawasaki |
| Engine name | FR Series | FR Series |
| Power output | 18 hp | 18 hp |
| Cylinder displacement | 603 cm³ | 603 cm³ |
| Cylinders | 2 | 2 |
| Engine cooling | Air | Air |
| Air filter type | Auto-type Paper | Auto-type Paper |
| Power/fuel type | Gasoline | Gasoline |
| Engine lubrication type | Full pressure with oil filter | Full pressure with oil filter |
| Oil filter | Yes | Yes |
| Fuel tank volume (with reserve) | 3.5 gal (US) | 3.5 gal (US) |
| Fuel tank location | Side (Single) | Side (Single) |
| Equipment | ||
| Seat material | Vinyl | Vinyl |
| Seat spring | Yes | Yes |
| Seat back height | High | High |
| Hour meter type | Digital with pre-programmed service intervals | Digital with pre-programmed service intervals |
| Cup holder | Yes | Yes |
| Hinged armrests | Optional | Optional |
| ROPS | No | No |
| Seat type | Comfort high back | Comfort high back |
