GrandStand 48 in. 22 HP 726cc (72504)

Product Highlights

• Improve productivity with easy access on and off the machine with up to 10.5 gallons of fuel capacity to mow longer with fewer stops.
• Exceptional visibility from the GrandStand protects the operator, the mower and the property. The operator is better able to steer clear of obstacles, and easily pass beneath branches.
• Toro’s foldable operator platform instantly converts the GrandStand to a walk-behind. It easily lowers back down when its time to ride – saving time, money and trailer space by eliminating the need to switch mowers.
• Conserves space to get more machines on your trailer, or allows for a smaller trailer and lighter load.

Specifications

• Engine22 hp (16.4 kw) Kawasaki FX 726cc
• Fuel CapacityGas/10.5 gal (39.7 L)
• Cutting Width48″ (122 cm)
• Adjustable Discharge BaffleStandard
• Air FilterHeavy-Duty Canister Air Cleaner
• Blade Tip Speed18,500+ ft/min
• Blade Type.25″ (.6 cm) heat-treated steel
• Carrier Frame3″ x 1.5″ (7.6 cm x 3.8 cm) x 12 gauge
• Caster Tires11″ x 5″-5″ (28 x 13-13 cm) flat free semi-pneumatic
• ClutchElectromagnetic
• Deck Design80-grade 7-gauge 48″ (122 cm) TURBO FORCE w/bull-nose bumper
• Discharge ChuteRubber
• Drive SystemPumps (10cc/rev) & Wheel Motors (10 cir)
• Drive Tires20″ x 10.5″- 8″ (51 x 26.67 – 20 cm)
• Engine Displacement726cc
• Ground SpeedUp to 10 mph forward (16.1 km/h)
• Height of Cut1″ – 5″ in 1/4″ (2.5 cm – 12.7 cm in 6 mm) increments
• Hour MeterStandard
• Hydraulic Fluid synthetic
• Spindle BearingsGreaseless ball bearings
• Spindle Housing9″ (22.9 cm) diameter cast aluminum
• Steering ControlsTwin lever
• Weight890 lbs. (403.7 kg)
