Hoffrichter Lavi 45 Portable Ventilator with HFT Function

The Hoffrichter LAVI 45 is a compact, portable ventilator designed for pressure-controlled, pressure-supported, and high-flow therapy. It is intended for invasive and non-invasive ventilation of adults and children (≥ 100 mL tidal volume) in both clinical and home-care environments. It combines modern turbine technology, high-flow oxygen therapy, and whisper-quiet operation for long-term use.

Features:

• Made in Germany: Designed and assembled to European quality standards.
• Compact and lightweight: 2.2 kg design with optional carry bag for mobile ventilation.
• Whisper-quiet operation: < 26 dB(A) using Hoffrichter Silence Technology (HST).
• Real-time monitoring: Pressure, flow and volume curves displayed continuously.
• Simple and intuitive menu navigation: Multifunction button + soft keys for quick access.
• Integrated HFT mode: Delivers humidified oxygen flow up to 60 L/min for respiratory support.
• Connectivity and cloud data: easySET software and Hoffrichter Cloud integration.
• Soft Start and Mask Test functions: Improve patient comfort and synchronization.

Hospital Benefits:

• Versatile for Multiple Care Levels: Supports both invasive and non-invasive ventilation, as well as high-flow oxygen therapy (HFT), allowing use across ICUs, HDUs, emergency, and ward setups without the need for separate devices.
• Portable and Lightweight: Weighs only 2.2 kg, enabling easy movement between patient rooms, departments, or during intrahospital transport, improving workflow efficiency.
• Low Noise Operation: Operating below 26 dB(A), it ensures a quiet and calm environment for both patients and medical staff, particularly valuable in neonatal and long-term care units.
• Energy Efficient: Uses advanced turbine technology with a maximum power consumption of just 75 W, reducing hospital power load while maintaining performance during 24×7 operation.
• Flexible Oxygen Management: Delivers 20 – 60 L/min flow with oxygen supply up to 15 L/min, compatible with both central pipelines and portable O₂ cylinders, making it suitable for critical and emergency care.
• Built-in HFT Mode: Integrated high-flow therapy mode eliminates the need for separate high-flow devices, saving space and equipment cost in hospitals.
• Reliable Backup Power: Equipped with a long-life lithium-ion battery providing up to 200 minutes of operation, ensuring patient safety during power interruptions or patient transfers.

Specifications:

• Power Consumption: Approx. 75 W (maximum).
• Battery Type: Rechargeable lithium-ion internal battery.
• High-Flow Therapy (HFT): Integrated adult HFT function with adjustable flow from 20 L/min to 60 L/min and oxygen input up to 15 L/min.
• Ventilation Modes: PCV, APCV, PSV, PSV-S, P-SIMV, CPAP, and HFT.
• Tidal Volume Range: ≥ 100 mL (for adults and paediatric patients).
• Dimensions (W × D × H): 215 mm × 203 mm × 115 mm.
• Weight: Approximately 2.2 kg.
• Noise Level: < 26 dB(A).
• Flow Capability: Up to 220 L/min without humidifilter and 175 L/min with humidifilter.
• Power Supply: AC 100 – 240 V, 50/60 Hz (external power supply).
